AW-UE80 4K Professional PTZ Camera
The AW-UE80W/K is a PTZ camera suitable for capturing the natural facial expressions of actors/performers and for recording events without spoiling the ambiance. The dome-shaped design minimizes “the feeling of being recorded on video” while the new direct-drive motor produces a very quiet operating sound so it won’t disturb the production activities or spoil the ambiance. The camera offers high-image-quality 4K/60p resolution, wide 74.1° angle, and optical zoom with up to 24x magnification to achieve superb video image quality. The AW-UE80W/K also offers excellent stability and security during video streaming so it can be used for any type of video production. From the production of a reality show to the recording of an internal business or educational event, the top-of-the-line standard model, AW-UE80W/K, can be used in a diversity of applications.
Built-in Auto-Tracking
The AW-UE80 now has the ability to track one-person at a time within frame, without an external PC or server. This auto-tracking feature has quick response times and accurate human body recognition – perfect for corporations, colleges/universities and other facilities that rely on presentation spaces. Panasonic Connect also offers external, software-based auto-tracking ideal for presentations with multiple people and cameras.
- Supports a wide variety of IP transmission protocols, including high bandwidth NDI*1, NDI|HX, and SRT*2
- Supports 4K 50p/60p shooting
- Includes a wide-angle lens with a 74.1° field of view and 24x optical zoom
- Supports FreeD for building AR/VR systems
- New Direct Drive System for improved responsiveness and quietness
- Still image JPEG capability
.jpg?width=42&height=25&name=0a2c763c0bf0a3edb3e77f884df1c8e4f3af0a32%20(1).jpg){kind=small}
- Panasonic Pro Audio + PTZ Camera Integration Brochure (PDF)
- AW-UE80 Installation Instructions (PDF)
- AW-UE80 IP Control Specifications (PDF)
- AW-UE80 Web Control Specifications (PDF)
- Interface Specifications Compatibility Guide (PDF)
- PTZ Camera PoE Hub Compatibility Chart (PDF)
- AW-UE80 Operation Manual
Featured Specs
| SKU | AW-UE80 |
|---|---|
| LENS | Motorized Optical 24x zoom, F1.8 to F4.0[f=4.12 mm (5/32 inches) to 98.9 mm (3‑29/32 inches);35 mm (1‑3/8 inches) equivalent: 25.0 mm (31/32 inches) to 600.0 mm (23‑5/8 inches)] |
| General | - |
| MINIMUM ILLUMINATION | 3 lx (F1.8, 59.94p, 50IRE, 42 dB, without accumulation) |
| Zoom |
|
| Horizontal Resolution | 1,500 TV Typ (Center area, UHD mode, wide)1,000 TV Typ (Center area, FHD mode, wide) |
| Input Connectors | DC 12 V IN, G/L IN(BNC)BBS (Black Burst Sync), tri-level sync supported) |
| Input/Output Connector | - |
| Gain Selection | Auto, 0 dB to 36 dB*3 (Super Gain function equipped : 37 dB to 42 dB) |
| WHITE BALANCE |
|
| Storage Temperature | -20 to 50°C (-4 °F to 122 °F) |
| VIDEO OUTPUT | - |
| Current consumption | 3.0 A (Supplied AC adaptor), 1.0 A (PoE++ power supply) |
| Power Requirements | 12 V DC (10.8 V to 13.2 V) (Supplied AC adapter) |
| Optical Filter | Through, 1/4, 1/16, 1/64, IR through (IR through is used as "night mode") |
| Output Format | - |
| Color separation optical system | 1MOS |
| Focus | Switching between auto and manual |
| Focus Distance | Entire zooming range: 1200 mm (3.9 ft)Wide end: 100 mm (0.33 ft) |
| Gamma | HD / Normal / Cinema1 / Cinema2 / Still Like |
| Scene File | - |
| Synchronization System | Internal/External synchronization (BBS/Tri-level sync) |
| Pan/Tilt Operation Speed | Speed range: 0.08°/s to 60°/s (Normal mode)*8
|
| Quietness | NC25 or less |
| Electronic Shutter Speed | - |
| Tilting Range | -30°to 90°*9 |
| Imaging Sensors | 1/2.5-type MOS×1 |
| Frame Mix | Auto, 0 dB, 6 dB, 12 dB, 18 dB, 24 dB*4 |
| Chroma Amount Variability | OFF, -99 ％ to 99 % |
| Ambient Operating Humidity | 20 ％ to 90 ％ (no condensation) |
| Finish | AW-UE80W: WhiteAW-UE80K: Black |
| Image Resolution | 1920×1080, 1280×720, 640×360, 320×180 |
| Panning range | ±175° |
| Camera Unit | - |
| Mass | Approx. 2.0 kg (4.41 lbs) (excluding ceiling mounting bracket),Approx. 2.25 kg (4.96 lbs) (including ceiling mounting bracket) |
| INPUT | - |
| OUTPUT | - |
| INPUT/OUTPUT | - |
| Installation Method | Stand-alone (Desktop) or suspended (Hanging)*7 |
| Camera/pan-tilt head control | - |
| Controller Supported | AW-RP150GJ, AW-RP60GJ, AW-RM50AG, AK-HRP1000*1, 2, AK-HRP1005*1, 2, AK-HRP1015*2, AK-HRP250*2 |
| Ambient Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Dimensions (W x H x D) (mm) | 170.0 mm x 211.0 mm x 171.0 mm |
| Dimensions (W x H x D) (inch) | 6.693 inches x 8.307 inches x 6.732inches |
| PoE++ | IEEE802.3bt compliant: DC42 to 57 V (Camera Input)(Software authentication (LLDP) is supported) |
| Conversion Lens | Not supported |
| Angle of View Range | Horizontal angle of view: 74.1° (wide) to 3.3° (tele)Vertical angle of view: 46.0° (wide) to 1.9° (tele)Diagonal angle of view: 81.8° (wide) to 3.8° (tele) |
| Syncro Scan | - |
| Supported operating systems and web browsers | - |
| IP Streaming | - |
| Image Streaming Mode | JPEG(MJPEG), H.264, H.265, NDI®|HX version 2*11, 12, 13 (H.264), High Bandwidth NDI® |
| Image Transmission setting (JPEG) | Frame rate: Maximum 30fpsImage quality (Fine / Normal) |
| Image Transmission Setting (H.264) | Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port Transmission Priority: Constant bit rate, Frame rate, Best effort Frame Rate: [60 Hz] 5fps / 15fps / 30fps / 60fps, [50 Hz] 5fps / 12.5fps / 25fps / 50fps Max Bit Rate: 512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps / 12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps |
| Image Transmission Setting (H.265) | Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port Transmission Priority: Constant bit rate, Frame rate, Best effort Frame Rate: [60 Hz] 30fps / 60fps, [50 Hz] 25fps / 50fps Max Bit Rate: 512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps / 12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps |
| Audio Compression Type | AAC-LC, 48 kHz, 16 bit, 2 ch |
| Pan Tilt Head Unit | - |
| Supported protocol | - |
| Note | *1:Discontinued Model*2:Will be supported in the future*3:Can be set in 1 dB step increments.*4:Cannot be set when the format is 2160/29.97p, 2160/23.98p, 2160/24p, 2160/25p, 1080/29.97p, 1080/23.98p (59.94i), 1080/29.97PsF, 1080/23.98PsF, 1080/25p, 1080/25PsF.*5:STP (Shielded Twisted Pair) is recommended.*6:Use Category 6 or higher when transmitting 4K video.*7:To ensure safety, the unit must be secured using the mount bracket supplied.*8:Note that the operating noise may be loud in high speed. If the operating noise is disturbing, use the Normal mode.*9:The main unit may appear in the video depending on the pan/tilt position.*10:Supported OS indicated are for browsers current as of August 2020. See “Service and Support / PASS” for the latest information on browser support.*11:NDI® is a new protocol developed by NewTek, Inc. that supports IP video production workflow.*12:NDI® is a registered trademark of NewTek, Inc. in the United States.*13:In this instance, NDI® is used to indicate low latency with high bandwidth NDI®, NDI®|HX is used to indicate high efficiency low bandwidth NDI®|HX. In the NDI®|HX mode, 4K video signals cannot be output. AW-UE80 supports NDI®|HX version 2 and Full HD output.*14:Simultaneous operation with the AW protocol is not possible.*15:Non-synchronous with SDI-OUT |
| Other Function | - |
| Tally LED display color | red / green |
| NDI Support | NDI®|HX version 2: Included as standardHigh Bandwidth NDI®: Included as standard*14 |
| Mic/line input | AAC compatibility (compatible with IP only)Φ3.5 mm stereo mini jack• During MIC inputInput level: -40 dBV (0 dB=1 V/Pa, 1 kHz)Supply voltage: 2.5 V±0.5 V (plug-in power compatible)"• Input impedance: Approx. 2 kΩ (when plug-in power is turned ON)Approx. 20 kΩ (when plug-in power is turned OFF)"• During LINE inputInput level: -10 dBVInput impedance: Approx. 3 kΩ• Input volume variable range: -36 dB to 12 dB (3 dB step)• Embedded audio output level: -12 dBFS• Sampling frequency: 48 kHz• Quantization bit rate: 24 bit (SDI, HDMI), 16 bit (IP) |
| IP connecting cable | • If you have a PoE++ ethernet hubLAN cable*5, 6 (category 5e or above, straight cable) Max 100 m (328 ft)• If you don't have a PoE++ ethernet hubLAN cable*5, 6 (category 5e or above, straight cable) Max 100 m (328 ft) |
| AW protocol connecting cable | LAN cable*5 (category 5e or above, straight cable) Max 1000 m (3280 ft) |
| Image Stabilization | OIS 2-axisMENU switching: Select between Off/O.I.S.(STABLE)/O.I.S.(PAN/TILT) |
| Electronic Shutter Speed | 59.94p/59.94i | 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| Electronic Shutter Speed | 29.97p | 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| Electronic Shutter Speed | 50p/50i | 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| Electronic Shutter Speed | 25p | 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| Input/Output Connector | LAN | LAN terminal for IP control (RJ-45) |
| Input/Output Connector | RS-422 | CONTROL IN RS422A(RJ-45) |
| Windows | Windows 10 Windows® Internet Explorer® 11(32 bit / 64 bit) Microsoft Edge Google Chrome |
| Mac | Mac OS v11.0.1 / Safari 14.01 Mac OS v11.0.1 / Google Chrome Mac OS v10.15 / Google Chrome Mac OS v10.14 / Google Chrome |
| Video Output | HDMI | HDMI 2.0 connector, 4:2:2/10bit• HDCP is not supported.• Viera Link is not supported |
| Supported protocol | IPv4 | TCP/IP, UDP/IP, HTTP, HTTPS, RTSP/RTP, MPEG2-TS, DHCP, DNS, DDNS, NTP, IGMP, ICMP, ARP, RTMP, RTMPS, SRT |
| Supported protocol | IPv6 | TCP/IP, UDP/IP, HTTP, HTTPS, DNS, NTP, DHCPv6, RTSP/RTP, MLD, ICMP, ARP, SRT |
| Output Formats | High Bandwidth NDI® : 【HD】1080/59.94p, 1080/50p, 1080/29.97p, 1080/25p, 1080/24p, 1080/23.98p, 720/59.94p, 720/50p |
| New Functions | - |
| Electronic Shutter Speed | 23.98p/24p | 1/24, 1/48, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| Synchro Scan | 59.94p/59.94i | 60.0 Hz to 7200 Hz |
| Synchro Scan | 29.97p | 30.0 Hz to 7200 Hz |
| Synchro Scan | 23.98p/24p | 24.0 Hz to 7200 Hz |
| Synchro Scan | 50p/50i | 50.0 Hz to 7200 Hz |
| Synchro Scan | 25p | 25.0 Hz to 7200 Hz |
| Output Format | SDI | HD | 1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native), 23.98p (over59.94i), 1080/29.97psF, 25psF, 23.98psF, 1080/24p (Just), 23.98p (Native), 720/59.94p, 50p |
| Output Format | HDMI | 4K | 2160/59.94p, 2160/50p, 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Just), 2160/23.98p (Native) |
| Output Format | HDMI | HD | 1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native), 23.98p (over59.94p), 1080/24p (Just), 23.98p (Native), 720/59.94p, 50p |
| Video Output | 3G-SDI OUT | SMPTE292M/424M/ 75 Ω(BNC×1)• Level-A/Level-B supported |
| Image Resolution | NDI®|HX version 2 | 1920x1080, 1280x720 |
| Audio Compression Type | High Bandwidth NDI® | AAC-LC, 48 kHz, 2 ch |
| Audio Compression Type | NDI®|HX version 2 | AAC-LC, 48 kHz, 16 bit, 2 ch |
| F-Number Display | Displayed on the AW-RP150GJ and AW-RP60GJ sides |
| Menu Display on IP Video | Supported*15 |
| Power LED | ON/OFF control |
| Tripod Screw Penetration Measures | Possible |
| Pan/Tilt Mechanical Method | New Direct Drive System |
| Privacy Mode | The lens surface faces backward when standing by (ON/OFF)* Default is OFF |
| VR Compatibility | Supports FreeD protocol |
| Android | Android OS Google Chrome |
| iPhone / iPad | iOS Safari iPadOS |
| Image Transmission Setting (High Bandwidth NDI®) | Transimission Type: TCP/UDP, Unicast/Multicast Max Bit Rate: 250 Mbps |
| Image Transmission Setting (NDI®|HX version 2) | Transimission Type: TCP/UDP, Unicast/Multicast |
Built-in auto-tracking for one-person presentations on-the-fly
The AW-UE80 now features auto-tracking built into the camera. This means no additional hardware or software is needed to have one subject kept in frame. This technology uses body recognition to keep someone on camera. This is an easy and effortless way for corporations and higher education facilities to provide remote or hybrid meetings with little setup.
Optical 24x Zoom & 74.1° Horizontal Wide Angle Lens
Adding "iZoom" to the AW-UE80's exceptional 24x optical zoom, maintains high resolution while enabling ultra-high resolution 36x zoom in HD mode. This enables distant subjects to be captured clearly. Furthermore, 74.1° horizontal wide-angle shooting allows you to capture the entire area with one camera, even when installation space is limited.
Versatile Video Outputs for a Range of Video Productions
The AW-UE80 supports three popular output interfaces, including 3G-SDI, HDMI and IP, providing you with a range of options for current camera installations, while also preparing you for future video workflows.
Multiple Control Options for Small or Large Scale Production
The AW-UE80 can be controlled via the web browser when connected to the network, allowing for quick and easy camera movement, preset access, and image adjustments. Additionally, the camera can be controlled using the AW-RM50 IR remote control and the AW-RP150 / AW-RP60 hardware-based camera controllers. These control choices make it easy to integrate the UE80 into your video production workflow.
An IP connection from the AW-RP150 Remote Camera Controller through a HUB (switching hub) enables control of up to 200 x AW-UE80 cameras. Furthermore, a single AW-UE80 unit can be controlled from up to 5 x AW-RP150 units.
Live AR/VR Video Production via FreeD Protocol
To be able to incorporate realistic VR (virtual reality) or AR (augmented reality) studio sets in your live productions, accurate camera positioning data is imperative. The AW-UE80 features the FreeD protocol, which provides you with the option to output Pan / Tilt / Zoom / Iris information via Serial (RS 422) and IP (UDP) directly from the camera to your AR/VR tracking system.
Flexible Installation & Mounting Options
Weighing only 4.4 lbs, the AW-UE80 is lightweight and compact enough for easy permanent or portable installs. It’s equipped with a turn lock mechanism for easy installation and comes standard with a safety cable for extra security and peace of mind.
Blend-in: The camera is exceptionally easy to integrate and is available in two colors (AW-UE80W: pearl white / AW-UE80K: black matte) to suit a wide range of applications.
Ceiling Mount: A twist-lock ceiling mount is included as a standard accessory.
Tripod Mount: The UE80 is also equipped with a 1/4-20 tripod mounting screw receptacle and a safety lanyard for use with many mounting and grip systems.
Wall Mount: An optional heavy-duty wall mount is available in either black (FEC-40WMK) or white (FEC-40WMW).
Pole Mount: Easily mount the UE80 to an A/V ceiling extension pole by pairing the FEC-40WM wall mount with the FEC-PA1 adapter.
Fresh New Web Interface
Camera IP image output, settings, and control can be performed using a web browser on a computer connected via an IP network. In addition to PCs and Macs, iPads, iPhones, Androids and other mobile devices can be used for operation, and this pursuit of easy-to-use interfaces has enabled smooth camera control from remote locations.
Supports SRT for Secure and Reliable Video Streaming
The AW-UE80 supports SRT, a next generation video transport protocol that provides robust security and works well even with an unstable network environment. This prevents trouble such as transmission interruptions during program production or event recording, thus assuring stable and reliable video streaming. This protocol can prevent risks such as information leakage, so it can be used safely for any video content.
Single Cable Installation with PoE++
With PoE++ technology , the AW-UE80 offers an optimal level of installation flexibility, providing not just power to the camera, but also enabling camera control and audio/video output, all via a single LAN cable. Using PoE++ with the UE80 camera simplifies cable runs, decreases overall installation costs, and in some cases, eliminates the need for having a dedicated electrician onsite for the install.
