4K CINELIVE Studio Camera with PL Mount
The AK-PLV100 4K PL-mount studio camera carries on the legacy of VariCam with a cinematic look, V-LOG and Dual Native ISO, and streamlines multicamera live shooting to deliver another purpose built studio camera for easy CINELIVE production.
- Equipped with a large format, 5.7K Super 35mm sensor and PL Lens mount to accommodate cinema lenses for shallow-depth of field
- Capture frame rate is switchable to Cinematic 24p/30p on a 60p system, users can easily switch between a 24p/30p look and a standard broadcast 60p look
- Outputs SMPTE ST2110* video directly from its camera head and merely requires an optical-fiber connection for return input, intercom input/output, PTP synchronization, trunk out, and tally input
- Compatibility with Panasonic's 2/3-inch studio-camera system equipment allows the use of CCUs (UCU600 and HCU250), ROPs (HRP1010 and HRP1015) and other accessories
- V-LOG output* for wide dynamic range and rich color gamut, along with Dual Native ISO* for superb low-light performance
Featured Specs
| SKU | AK-PLV100GSJ |
|---|---|
| Weight | Approx. 4.2 kg (9.26 lbs.) (body only, excluding the accessories) |
| Dimensions (W x H x D) | Body only 151 mm x 267 mm x 389 mm (5-31/32 inches x 10-17/32 inches x 15-11/32 inches) (excluding protrusions) |
| Operating temperature | -10 °C to 45 °C (14 °F to 113 °F) (Preheating required under a temperature 0°C (32 °F) or below) |
| Operating humidity | 85% or less (relative humidity) |
| General | -- |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Power supply | DC 12 V (when using an external power supply) DC 190 V (when AK-HCU250PSJ/HCU250ESJ is connected) AC 240 V (when AK-UCU600PSJ/ UCU600ESJ is connected) |
| Power supply | DC 12 V (when using an external power supply) DC 190 V (when AK-HCU250PSJ/HCU250ESJ is connected) AC 240 V (when AK-UCU600PSJ/ UCU600ESJ is connected) |
| Lens Mount | 35mm PL Mount |
| Horizontal Resolution | 4K: 2000 TV lines (center) |
| Optical Filter | ND: Clear, 1/4, 1/16, 1/64 |
| S/N | 62 dB or above |
| Camera Unit | - |
| System format | 3840x2160/59.94p/50p/29.97p/25p/23.98p 1920x1080/59.94p/50p/29.97p/25p/23.98p |
| Video input/output | - |
| Pickup device | S35mm 17.25 million pixels MOS Sensor |
| <AUX> terminal | BNCx1 |
| <SDI OUT1(12G)> terminal | BNCx1 12G/6G/3G/1.5G-SDI:0.8 V[p-p], 75 Ω |
| <SDI OUT2> terminal | BNCx1 3G/1.5G-SDI:0.8 V[p-p], 75 Ω |
| Intercom | - |
| Audio Input/Output | - |
| OTHER INPUT/OUTPUT | - |
| <MIC 2> terminal | XLR x 1, 3-pin (female type)[LINE]/[MIC]/[+48V] switchable[LINE]: 0 dBu[MIC]: -60 dBu, -40 dBu, or -20 dBu menu can be selected |
| <MIC> terminal (front) | XLR x 1, 3-pin (female type)[LINE]/[MIC]/[+48V] switchable[LINE]: 0 dBu[MIC]: -60 dBu, -40 dBu, or -20 dBu menu can be selected |
| <INTERCOM1> terminal | XLR x 1, 5-pin, female type |
| <OPT FIBER> terminal | Optical composite connector x 1 |
| <LENS> terminal | 12-pin x 1 |
| <VF> terminal | 20-pin x 1 |
| <VF> terminal (rear) | 29-pin x 1 |
| <DC IN> terminal | XLR x 1, 4-pin, DC 12 V |
| <LAN> terminal | RJ-45x1 |
Cinematic Video with Shallow Depth of Field
The AK-PLV100GSJ comes with a 5.7K Super 35mm sensor and PL mount to produce cinematic video with bokeh effects. Combining the visual beauty of a cinema camera with the operability of a studio camera, the AK-PLV100GSJ achieves live video for events and sports with rich visual expression that grabs viewers attention.
- Dual Native ISO for high sensitivity and low noise1
- Simultaneous HLG/ITU-R BT.2020 (4K mode) and SDR/ITU-R BT.709 (HD mode)
- V-LOG output for wide dynamic range and rich color gamut1
Simple Operation without CCU
Normally, live production with a cinema camera requires the use of many external devices, but with the AK-PLV100GSJ, only the camera is needed to build a system. The AK-PLV100GSJ outputs SMPTE ST2110 video directly from its camera head and merely requires an optical-fiber connection for return input, intercom input/output, PTP synchronization, trunk out, and tally input.
Input/output method for camera head alone
HD mode: Uncompressed SMPTE ST2110 input/output standard1
4K mode: SMPTE ST2110 output with JPEG-XS compression standard1
12G-SDI output standard
Input/output method for camera head alone
HD mode: Uncompressed SMPTE ST2110 input/output standard1
4K mode: SMPTE ST2110 output with JPEG-XS compression standard1
12G-SDI output standard
SMPTE ST2110 output from camera head (Future support planned via firmware update)
12G-SDI output from camera head
Compatible with 2/3-inch Studio Camera Equipment
Compatibility with Panasonic’s 2/3-inch studio-camera system equipment allows the use of CCUs, ROPs and other accessories. Under this new concept for live production, the camera head is selected according to the desired expression.
12G/3G/1.5G-SDI output from CCU
SMPTE ST2110 output from CCU using optional IP/12G/3G Interface Kit
Compatible devices: AK-UCU600PSJ/ESJ, AK-HCU250PSJ/ESJ, AK-HRP1010GJ, AK-HRP1015GJ and AK-MSU1000GJ
AK-PLV100 Studio Camera System Features
- Compatibility with Panasonic’s 2/3-inch studio-camera system equipment allows the use of CCUs, ROPs and other accessories. Under this new concept for live production, the camera head is selected according to the desired expression.
- Capture frame rate is switchable to Cinematic 24p/30p on 60p system, so can easily switch between a 24p/30p look and a standard broadcast 60p look.
- Digital extender with signal-processing circuitry for 2x image magnification
- Remote switching of motorized ND filter
- Focus assist (Focus in Red/MAG/Focus Square) for fast, accurate focusing
- Fine adjustment of saturation and hue separately using 12-axis color correction and linear matrix
- Beautiful, natural-looking skin thanks to wrinkle and tone correction
- Shockless gain smooths out images during gain changes
AK-PLV100GSJ Studio Camera System
1 / * Future support planned.
